A collection of high-quality Revit families that you can use in your engineering projects.
This collection includes four types of tracks and seven types of lights, all of which can be used interchangeably with any track type. These families cater to all your needs when it comes to designing and utilizing magnetic lighting systems.
Track Installation:
The tracks can be mounted on any surface in your project, such as walls, ceilings, or other surfaces.
Track Types:
- Square shape
- U-shape
- L-shape
- I-shape
You can select the shape that best suits your project, and you’ll have full control over all dimensions and parameters for each track type, allowing access to a wide range of options and capabilities.
Lighting Fixtures:
In addition to tracks, the attached file includes several types of lights that can be installed on the tracks.
Lighting Types:
- Linear Light
- Linear Spotlight
- Pendant Linear Light
- Pendant Spotlight
- Foldable Linear Light
- Foldable Linear Spotlight
- Adjustable Track Spotlight
Choose the lighting fixture that fits your project, with full control over dimensions and parameters for each type, providing extensive customization options.
Notes:
- Track and light installation in Revit mimics real-life processes:
- First, the track is mounted on the surface, and its dimensions are adjusted as per the designer’s choices.
- Next, the lighting base is installed inside the track.
- Direct mounting option:
All lighting fixtures can also be mounted directly on the required surface without using a track, which can be beneficial in specific design scenarios. - Support:
If you encounter any issues while using these families, don’t hesitate to contact us.
–
Revit Version: 2018
Units System: Metric
